- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1958
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 134665
Sams Photofact Folders reference picture.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 105-120 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 15 inch = 38.1 cm
- Power out
- 30 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: F-1900 - Philco, Philadelphia Stg. Batt
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- The Philco Model F-1900 is an AC operated 5 Tube Phono Amplifier with push-pull output stage and a 4 Speed Record Changer. Uses Record Changer M-39 delux with speeds of 16-2/3, 33-1/3, 45 and 78 RPM. 7", 10" and 12" records may be intermixed and there is an automatic shut-off feature that turns off the entire record player at the end of the last record. This model has Qty(1) 15" PM woofer, 20-2000 Hz and Qty(1) large electrostatic "cathedral" speaker with 66 sections on a cylindrical surface, 2000-20,000 Hz. Cabinet is Blonde, Fruitwood or Mahogany.
- Mentioned in
- Philco Home Radio Yearbook 1958
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 1-59, Set 427, Folder 10)
- Literature/Schematics (2)
- - - Manufacturers Literature
- Author
- Model page created by Thomas Albrecht. See "Data change" for further contributors.
