- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1960 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 104115
Note separate tuning controls for AM and FM.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- AC/DC-set / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: H984 - Philco, Philadelphia Stg. Batt
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 12 x 6.5 x 6 inch / 305 x 165 x 152 mm
- Notes
- With selenium rectifier. Light aqua (blue-green) plastic cabinet. Sams photofact set 507 folder 13 date 11-60 features this model as H984AQ.
- Source of data
- - - Data from my own collection
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 507 folder 13 date 11-60)
- Author
- Model page created by Thomas Albrecht. See "Data change" for further contributors.
