M-8 Automatic Record Changer

• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1947

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 51421

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: M-8 Automatic Record Changer - Philco, Philadelphia Stg. Batt

• Shape
• Chassis only or for «building in»

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 19 = 1949 and before

• Literature/Schematics (1)
• - - Manufacturers Literature (Philco Service Manual - Automatic Record Changer model M-8)

• Other Models

• Here you find 4068 models, 2221 with images and 3717 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
