• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 93066

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 117 / 6 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: NT-1004 - Philco, Philadelphia Stg. Batt

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• Made in Japan

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 25, 1965

• Mentioned in
• Collector's Guide To TrR1 Bunis trans.94 (1996, page 201)

• Literature/Schematics (1)
• Photofact TSM Transistor Radio Series SAMS (TSM-50, February 1965)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
