Predicta Holiday UG4242L Ch= 9L37U
Philco, Philadelphia Stg. Batt. Co.; USA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1959
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 126794
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 5X8 4BC8 2AF4A 3BZ6 3BZ6 5AM8 3AU6 3BN6 12CA5 6AW8A 9BR7 10DE7 6CG7 12DQ6A 1G3GT 12D4 21EAP4 or SF21A
- Main principle
- Superhet with RF-stage; ZF/IF 45750 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 4 inch = 10.2 cm
- Material
- Various materials
- from Radiomuseum.org
- Model: Predicta Holiday UG4242L Ch= 9L37U - Philco, Philadelphia Stg. Batt
- Shape
- Tablemodel, with any shape - general.
- Notes
- The Philco UG4242L is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 9L37U, VHF tuner T-69K, UHF tuner T-27F and picture tube 21EAP4 or SF21A. Cabinet is Blonde. Swiveling top-mount CRT enclosure. Built-in telescoping antenna.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 439 Folder 1 4-1959)
- Literature/Schematics (2)
- - - Manufacturers Literature
- Author
- Model page created by a member from A. See "Data change" for further contributors.
