• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1972 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 353739

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: R89 - Philco, Philadelphia Stg. Batt

• Shape
• Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).

• Dimensions (WHD)
• 11.5 x 12.5 x 8.25 inch / 292 x 318 x 210 mm

• Notes

• Cathedral Radio Special Edition Model R89 80TH Anniversity.  Cabinet resembles a Philco Baby Grand (many models).

  RCA phono audio output jack, located on the back.





• Net weight (2.2 lb = 1 kg)
• 5.5 lb (5 lb 8 oz) / 2.497 kg

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 1370, Folder 6, Jan. 1974 for R89WA)

• Author
• Model page created by Lester Troeckler. See "Data change" for further contributors.

• Other Models

• Here you find 4063 models, 2220 with images and 3711 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Philco, Philadelphia Stg. Batt. Co.; USA
