• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 72199

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• T-1033 T-1459 T-1460 T-1001 T-1007 T-1007

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / D: 2 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm

• Power out
• 0.1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Transistor T65-124 - Philco, Philadelphia Stg. Batt

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Notes

• The Philco Model T-65 is a Battery operated 6 transistor and 1 diode portable AM Receiver. BC Band Tuning Range: 535 to 1620KHz. This model has Qty(1) 3.5" PM speaker. Uses Qty(2) 1.5V D cells. Cabinet is Ivory and Turquoise or Ivory and Gold. See also SAMS Photofact Folder Date 1959, Set 454, Folder 18-S.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 12-59, Set 468, Folder 10)

• Literature/Schematics (2)
• - - Manufacturers Literature (Philco Transistor Radio Service Manual PR-3311 Dated 1959)

• Literature/Schematics (3)
• Beitman Radio Diagrams, Vol. 19, 1959 (Page 107)

• Author
• Model page created by Hinrich Grensemann † 15.5.16. See "Data change" for further contributors.

• Other Models

• Here you find 4041 models, 2218 with images and 3690 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Philco, Philadelphia Stg. Batt. Co.; USA
