UH4686SL Ch= 10L60U
Philco, Philadelphia Stg. Batt. Co.; USA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1959 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 143834
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- 6BC8 6X8 6AF4A or 6AF4B 6DE6 6DE6 6AM8 12BV7 12AZ7 6BY8 6CS6 6BQ5 6CG7 6DT5 6CG7 6DQ6A 6AU4 1G3GT 5U4GB 21EAP4
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 105 - 120 Volt
- Loudspeaker
- 3 Loudspeakers
- from Radiomuseum.org
- Model: UH4686SL Ch= 10L60U - Philco, Philadelphia Stg. Batt
- Notes
- The Philco UH4686SL is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 10L60U, VHF tuner T-101C, UHF tuner T-28D and picture tube 21EAP4.
Sams photofact set 476 folder 2 date 3-60 features the Philco models H4686S, H4686SL with chassis 10L60, the models H4686SLR, H4686SR, H6636SLR, H6636SR, H6636SWR with chassis 10L60R, the models UH4686S, UH4686SL with chassis 10L60U, the models UH4686SR, UH4686SLR, UH6636LR, UH6636SR, UH6636SWR with chassis 10L60UR as the same schematic.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 476 folder 2 date 3-60)
- Literature/Schematics (2)
- - - Manufacturers Literature
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
- Other Models
-
Here you find 4041 models, 2218 with images and 3690 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Philco, Philadelphia Stg. Batt. Co.; USA
