Radioplayer 115B
Philips Australia
- Country
- Australia
- Manufacturer / Brand
- Philips Australia
- Year
- 1949 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 263658
RECONSTRUCTED LABEL
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 220-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Radioplayer 115B - Philips Australia
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 440 x 335 x 200 mm / 17.3 x 13.2 x 7.9 inch
- Notes
-
This model is the same as the Philips 115A except for the tuning capacitor and dial scale.
See also Mullard version, Model MAS1107B.
- Literature/Schematics (1)
- - - Manufacturers Literature (Philips Radioplayer Service Data Modification Sheet.)
| Radioplayer 115-A-B-D service manual | 1108 KB |
- Documents regarding this model
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
