• Country
• Australia

• Manufacturer / Brand
• Philips Australia

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 266159

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 6AN7 6N8 EF86 12AT7 EM34 6M5 6M5 6BD7 6M5 5V4G

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 6 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 200-230; 240-250 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 178C - Philips Australia

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Separate amplifiers are used for the low and high audio frequencies. The record changer is a Philips type AG1000. This model differs from the 178B in the type of I.F. transformers used.

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.
