• Country
• Italy

• Manufacturer / Brand
• Philips Italy; Milano (MI)

• Year
• 1958

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 318361

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• PCC88 PCF80 EF80 PCF80 PCF80 PCF80 PCF80 PL36 PY81 DY87 PCL82 EF80 PCL82 PY82 PY82 AW43-80

• Main principle
• Superheterodyne (common); ZF/IF 42500 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 145; 160; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mantova 17TI183A /02 - Philips Italy; Milano MI

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 400 x 480 x 400 mm / 15.7 x 18.9 x 15.7 inch

• Notes

• Philips S.p.A. 17TI183A /02

  TV B/N 17" con sintonizzatore rotativo di VHF.

  FI: 1ª 44.0 MHz, 2ª 42,5 MHz y 3ª 45,2 MHz.

  • Tubo catodico con deflessione di 90° tipo AW43-80;
  • 12 canali compresa banda UHF;
  • Consumo 120 w;
  • Regolatore di tono rotativo;
  • Altoparlante tipo AD3460X.

• Price in first year of sale
• 140,000.00 ITL

• Mentioned in
• Catalogo ANIE (1958/59 no.4 p.263)

• Author
• Model page created by Toni Gutiérrez García. See "Data change" for further contributors.
