- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1975 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 225253
Picture from manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 53
- Semiconductors
- BC548 BF494 BD137 BC559 BC549 BC558 BD313 BD314 BD138 BC638 BC546 BD677 BC547 BC557 BC338 µA723 TBA570 TDA1005 NE542 NE545
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Record Player + Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 80 W (120 W max.)
- from Radiomuseum.org
- Model: 22AH994 /29 - Philips; Eindhoven tubes
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 645 x 130 x 423 mm / 25.4 x 5.1 x 16.7 inch
- Notes
-
Player type 22GC037.
Each semiconductor listed once.
