22AC890 /00
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1979 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 84796
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 22
- Semiconductors
- BF324 BF495 BF240 BF494 BF241 BC548 BC549 AN101 TDA1005 TDA1006 TDA1010 SAA1058 CD4024 CD4023 CD4007 CD4519 TMS3707 µA7805 BA315 BB417 AA119 BZX79 BAW62 BYX36 CQY95 CQY54
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: 22AC890 /00 - Philips Radios - Deutschland
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 180 x 43 x 155 mm / 7.1 x 1.7 x 6.1 inch
- Notes
-
Philips Digital 890, Vollstereo-Cassetten-Autoradio mit analoger Abstimmung und digitaler Frequenzanzeige. Turnolock-Speicher für 6 Sender (3x UKW, 2x MW und 1x LW). 2 x 6 Watt Ausgangsleistung in IC-Technik.
Cassettenspieler mit rastbarem schnellen Vor- und Rücklauf sowie ESC-Autostop.
Siehe auch Philips 22AC894 mit Verkehrsfunk-Decoder bei sonst gleicher Ausstattung.
Halbleiter sind einmal pro Typ gelistet.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Hugo Sneyers. See "Data change" for further contributors.
