• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1976 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 80015

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors
• TAA450 TAA450

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Wired Wireless Receiver (RF!)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: 22RH621 /16Z - Philips; Eindhoven tubes

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 420 x 120 x 285 mm / 16.5 x 4.7 x 11.2 inch

• Notes

• HiFi-Tuner mit 3fach-Drehko AM, Bandbreiten-Umschalter AM - wichtig für HF-TR, Ferritantenne. On/Off, FM Varicap mit 5 Preset, Schwungmasse, Holzdeckel, Rest Kunststoff, Schrägskala und Knöpfe, Design-mässig passend Verstärker 521, 551, 561 ua - typisch Philips 1972..76.

• Net weight (2.2 lb = 1 kg)
• 4.6 kg / 10 lb 2.1 oz (10.132 lb)
