22RL382 /00B /00R
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1968 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 241755
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz; 3 AF stage(s)
- Tuned circuits
- 5 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Dry Batteries / 4 x 1.5 & 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.4 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 22RL382 /00B /00R - Philips; Eindhoven tubes
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 279 x 135 x 56 mm / 11 x 5.3 x 2.2 inch
- Notes
-
- 2 cabinet colors: /00R = black, /00B =beige.
- AM radio with built-in ferroceptor:
- LW: 150 - 260 kHz.
- BC: 525 - 1622 kHz.
- FM radio with telescopic antenna: 87.5 - 104 MHz.
- Amplifier: 1 x 400 mW in 15 Ohm.
- Power supply: 6V (radio); 7.5V (amplifier).
The extra 1.5V battery serves to increase the output amplifier supply voltage.
