• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1971 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 324700

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 15

• Semiconductors
• BF195 BF194 BF195 BC149 BC149 BC148 AC127 AC128 AC127 AC128 AC126 AC127 AC128 AC127 AC128

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / AC: 110; 220 / 6 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AM-Radiorecorder RR30 22RR293 /00R - Philips; Eindhoven tubes

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 335 x 203 x 92 mm / 13.2 x 8 x 3.6 inch

• Notes

• Siehe auch die belgische Ausführung 22RR293.

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Gidi Verheijen. See "Data change" for further contributors.
