- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1972 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 250525
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 20
- Semiconductors
- BF195 BF195 BF195 BF194 BF195 BF195 BC149 BC148 BC148 BC158 AC187 AC188 AC127 AD161 AC127 AC128 BC149 BC148 BC159 AD161
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- 110-127 / 220-245 / 5 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 22RR650 /22 - Philips; Eindhoven tubes
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 325 x 220 x 90 mm / 12.8 x 8.7 x 3.5 inch
- Notes
-
UKW bis 104 MHz. Batterien vom Typ " Mono ".
Schaltplan siehe Philips 22RR712, nur geändertes Gehäuse
