• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Philips Electrical Industries of New Zealand Ltd.; Wellington

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 176033

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECH42 EF41 EBC41 EL41 EZ40

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.5 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 234 - Philips Electrical Industries

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 450 x 315 x 200 mm / 17.7 x 12.4 x 7.9 inch

• Notes

• See also Mullard Model 541 broadcast and Philips Model 235 3 band receivers.

• Price in first year of sale
• 27.30 NZ £

• Literature/Schematics (1)
• -- Schematic (From NZVRS Schematics and Service Manuals library.)

• Literature/Schematics (2)
• -- Original prospect or advert (Otago Daily Times (Dunedin), 7 October, 1950. Page 5.)

• Author
• Model page created by Aglef Tröger. See "Data change" for further contributors.
