Philips Australia
- Country
- Australia
- Manufacturer / Brand
- Philips Australia
- Year
- 1946
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 180416
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 472.5 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage and/or dry batteries / 135 & 2 or 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 2650 - Philips Australia
- Shape
- Tablemodel, low profile (big size).
- Notes
- This model could be powered from H.T. & L.T. batteries or from a 6 volt accumulator using a type 440B synchronous vibrator power unit.
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. V
- Literature/Schematics (1)
- Mingay's Radio Diagram & I.F. Index
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
