• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1939/1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 26888

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EF9 ECH3 EF9 EBF2 KC3 KDD1

• Number of Transistors

• Semiconductors
• 7946

• Main principle
• Superhet with RF-stage; ZF/IF 452 kHz

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Storage and/or dry batteries / 6 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• Material
• Wooden case

• from Radiomuseum.org
• Model: 292V - Philips; Eindhoven tubes

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 530 x 380 x 270 mm / 20.9 x 15 x 10.6 inch

• Notes
• Wave Bands. LW: 745-2000m, MW: 163-563m, SW2: 45-163m, SW1: 13.6-45m

• Net weight (2.2 lb = 1 kg)
• 15.8 kg / 34 lb 12.8 oz (34.802 lb)

• Price in first year of sale
• 195.00 Hfl

• Source of data
• -- Original-techn. papers.

• Mentioned in
• Technisch- Commercieel - Radio Vademecum Staleman

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
