371A

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Philips Electrical, Lamps, Industrial - Miniwatt; London

• Year
• 1947

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 99384

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECH35 EF39 EBC33 EL33 AZ31

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-260 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 371A - Philips Electrical, Lamps,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 16.5 x 9.25 x 8.25 inch / 419 x 235 x 210 mm

• Notes
• power consumption: 42.5 watts

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by Bruno Gandolfo-Canepa. See "Data change" for further contributors.
