3 Way Bass Reflex System FB277 70FB277 /02P
Philips Belgium (Belgien)
- Country
- Belgium
- Manufacturer / Brand
- Philips Belgium (Belgien)
- Year
- 1987/1988
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 290654
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- No Power needed
- Loudspeaker
- 3 Loudspeakers
- Power out
- 60 W (120 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 3 Way Bass Reflex System FB277 70FB277 /02P - Philips Belgium Belgien
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 280 x 625 x 220 mm / 11 x 24.6 x 8.7 inch
- Notes
-
PHILIPS 70FB277 /02P - bass reflex system - electronic overload protection - hight efficiency - impedenza 4-8 Ω - woofer cone : diam. 180 mm (frequency range 40/3.000 Hz) - super soft dome squawker: diam: 25 mm (frequency range 5.000/20.000 Hz) - super soft dome tweeter : diam. 18 mm (frequency range 10.000/20.000 Hz).
Made in Belgium.
- Net weight (2.2 lb = 1 kg)
- 6.7 kg / 14 lb 12.1 oz (14.758 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
