• Country
• Switzerland

• Manufacturer / Brand
• Philips - Schweiz

• Year
• 1943/1944

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 13344

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH21 EF22 EF22 EBL21 EM4 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 473 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: 447AGS - Philips - Schweiz

• Dimensions (WHD)
• 605 x 390 x 355 mm / 23.8 x 15.4 x 14 inch

• Notes
• S=Saphir

• Price in first year of sale
• 800.00 SFr

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Circuit diagram reference
• Thali-Schemasammlung und Tungsram-Röhrenbestückung.

• Other Models

• Here you find 290 models, 216 with images and 224 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
