• Country
• Poland

• Manufacturer / Brand
• Philips - Polskie Zaklady Philips

• Year
• 1937/1938 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 356341

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• KK2 KF4 KB2 KL4

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage and/or dry batteries / 2 & 150 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 4-38B - Philips - Polskie Zaklady

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 500 x 265 x 180 mm / 19.7 x 10.4 x 7.1 inch

• Notes

• See also Philips model 627B (in other countries).

• Net weight (2.2 lb = 1 kg)
• 8.4 kg / 18 lb 8 oz (18.502 lb)

• Author
• Model page created by Marcin Seliwiak. See "Data change" for further contributors.

• Other Models

• Here you find 52 models, 39 with images and 22 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
