• Country
• Belgium

• Manufacturer / Brand
• Philips Belgium (Belgien)

• Year
• 1941 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 330971

• Number of Tubes
• 4

• Valves / Tubes
• ECH3 EF9 CBL1 CY1

• Main principle
• Superheterodyne (common); 1 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 655U - Philips Belgium Belgien

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 490 x 330 x 250 mm / 19.3 x 13 x 9.8 inch

• Notes

• See also Philips model 655U (NL).

• Author
• Model page created by Gidi Verheijen. See "Data change" for further contributors.

• Other Models

• Here you find 593 models, 569 with images and 342 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
