• Country
• Switzerland

• Manufacturer / Brand
• Philips - Schweiz

• Year
• 1944/1945

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 156078

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH3 or ECH4 ECH21 EBL1 AZ1

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245; Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 671A/3 [4 Röhren] - Philips - Schweiz

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 435 x 286 x 198 mm / 17.1 x 11.3 x 7.8 inch

• Notes
• Alternativröhren ECH3 oder ECH4 ausnahmsweise nicht einfacher Austausch, sondern Fertigungsänderungen (Kriegsbedingt).

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
