- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1980 ??
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 206489
Picture from manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 14,4 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 8 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: 79AC658 /30 - Philips; Eindhoven tubes
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 160 x 51 x 120 mm / 6.3 x 2 x 4.7 inch
- Notes
- Stereo output 2x 4W.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
