• Country
• Spain

• Manufacturer / Brand
• Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona

• Year
• 1980 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 170664

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• ED1402 or. BC548 ED1502 or. BF494 ED1602 or. BC558 ED1702 or. BC338 ED1802 or. BC328 MM5420

• Main principle
• Superheterodyne (common); ZF/IF 468/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 90-AS-090 [/00/01/40/45/60] - Philips Ibérica, COPRESA,

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Notes
• Several variants:
  /00/40: FM= 87,5-104 MHz. FI/ZF= 468 kHz.
  /01/45/60: FM=87,5-108 MHz. FI/ZF= 455 kHz.
  Red/Mains:
  /60= 110V @ 60Hz.
  /00/01/40/45= 220V @ 50Hz.
  Semiconductors only once listed.

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
