Prinz 071 90AL071

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1977/1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 81417

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• ED1502 ED1402 ED1402 ED1402 ED1802 ED1802 CDG00 CDG27

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 2 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch

• Power out
• 0.13 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Prinz 071 90AL071 - Philips; Eindhoven tubes

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 75 x 112 x 36 mm / 3 x 4.4 x 1.4 inch

• Notes

• Wellenbereich: MW 520 - 1605 kHz. Ferritstab-Antenne. HP Z = 8 Ω.

  Also known with IF = 460kHz, which likely depends on the type number suffix (execution number).

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Source of data
• Handbuch VDRG 1977/1978
