FM - MW PLL Digital Receiver AE6209

Philips; Eindhoven (tubes international!); Miniwatt

Data

Forum

Pictures

Collections

Country
Netherlands

Manufacturer / Brand
Philips; Eindhoven (tubes international!); Miniwatt

Year
1989

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
257443

Schematics

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 1717389) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 1717388) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 1717392) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048014) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048015) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048016) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048018) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048019) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048020) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048022) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048023) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

FM - MW PLL Digital Receiver AE6209; Philips; Eindhoven (ID = 2048177) Radio — Philips; Eindhoven FM - MW PLL Digital Receiver AE6209 (1)

Technical Specifications

Number of Transistors
Semiconductors present.

Semiconductors

Main principle
PLL, Phase-locked loop

Wave bands
Broadcast (BC) and FM or UHF.

Power type and voltage
Dry Batteries / AAA: 2× 1,5 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 cm = 1.4 inch

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: FM - MW PLL Digital Receiver AE6209 - Philips; Eindhoven tubes

Shape
Very small Portable or Pocket-Set (Handheld) < 8 inch.

Dimensions (WHD)
60 x 100 x 20 mm / 2.4 x 3.9 x 0.8 inch

Notes
FM - MW PLL Digital Receiver
2×5 Presets
Sleep and Clock functions

Made in Korea.

Net weight (2.2 lb = 1 kg)
0.2 kg / 0 lb 7 oz (0.441 lb)

Author
Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
