• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1961–1963

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 20365

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• PCC88 PCF801 PC88 PC86 EF183 EF183 EF80 PCL84 EF80 PCL86 ECH84 ECC82 EAA91 PCL85 ECH84 PL500 PY88 DY86 AW47-91

• Conflicting model year with tube data.
• The model date contradicts tube dates. [ PCF801 (1962)]

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Colonel de luxe T14 864.709.10 - Nordmende, Norddeutsche Mende-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 575 x 420 x 320 mm / 22.6 x 16.5 x 12.6 inch

• Notes

• VHF/UHF

• Net weight (2.2 lb = 1 kg)
• 19.4 kg / 42 lb 11.7 oz (42.731 lb)

• Price in first year of sale
• 1,175.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1961/62

• Literature/Schematics (1)
• -- Original-techn. papers.
