Bi-Ampli AG9008
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1956 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 227592
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 145; 165; 220; 245 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 12 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Bi-Ampli AG9008 - Philips; Eindhoven tubes
- Shape
- Chassis only or for «building in»
- Notes
-
Philips AG9008 is a mono integrated amplifier, with several phono equalization settings.
Bi-Ampli principle: Treble and bass channel with separate output transformerless (OTL) amplifiers. Output power 6 watts per channel @ 6% distortion (90 and 4000 Hz measuring frequency).
Required loudspeaker impedance: 800 Ω
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by a member from CY. See "Data change" for further contributors.
