• Country
• Argentina

• Manufacturer / Brand
• Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 241391

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• UCH41 UAF41 UAF41 UL41 UY41

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz

• Wave bands
• Broadcast and Short Wave (SW).

• Details
• Changer (Record changer)

• Power type and voltage
• Line (AC, UC or DC not known) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Power out
• 2 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: AL-4663A - Philips Argentina, FAPESA,

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 680 x 800 x 380 mm / 26.8 x 31.5 x 15 inch

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Jorge Mochkovsky. See "Data change" for further contributors.

• Other Models

• Here you find 275 models, 170 with images and 198 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
