• Country
• Argentina

• Manufacturer / Brand
• Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires

• Year
• 1940 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 328596

• Number of Tubes
• 5

• Valves / Tubes
• PH4 PF9 PBF2 25L6G 25Z6G

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 200-220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: AL 542H /62 - Philips Argentina, FAPESA,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 380 x 280 x 200 mm / 15 x 11 x 7.9 inch

• Author
• Model page created by Rodolfo Gaston Wenceslao Nasasta. See "Data change" for further contributors.

• Other Models

• Here you find 275 models, 170 with images and 198 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
