• Country
• Argentina

• Manufacturer / Brand
• Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires

• Year
• 1950 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 181918

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• UCH42 UAF41 UAF41 UL41 UY41

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: AL-A50-A - Philips Argentina, FAPESA,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 400 x 270 x 410 mm / 15.7 x 10.6 x 16.1 inch

• Notes
• Negative feedback.
  Shortwave: 5.8 - 12.5 MHz.
  Philips record player model 2977/00.

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Jorge Mochkovsky. See "Data change" for further contributors.
