B0LN95U/00
Philips Portugal
- Country
- Portugal
- Manufacturer / Brand
- Philips Portugal
- Year
- 1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 86176
-
- Brand: FAPAE
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 110; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: B0LN95U/00 - Philips Portugal
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 261 x 142 x 142 mm / 10.3 x 5.6 x 5.6 inch
- Net weight (2.2 lb = 1 kg)
- 1.5 kg / 3 lb 4.9 oz (3.304 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Jose Duarte Costa. See "Data change" for further contributors.
