• Country
• Belgium

• Manufacturer / Brand
• Philips Belgium (Belgien)

• Year
• 1958/1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 29665

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UCC85 UCH81 UF89 UABC80 UL84 UY85

• Main principle
• Superheterodyne (common); ZF/IF 452/10700 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• AC/DC-set / 110-127; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: B3X81U /01 - Philips Belgium Belgien

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 286 x 189 x 170 mm / 11.3 x 7.4 x 6.7 inch

• Notes
• AM radio with built-in ferroceptor:
  • LW: 150 - 400 kHz.
  • BC: 517 - 1600 kHz.
  • SW: 6,0 - 12,08 MHz.
  FM radio with dipole antenna input: 87.5 - 100 MHz.

  Oval loudspeaker AD2460X.

  Dial lamp: 8089D-00 (12V / 100mA).

  4 verschiedene Skalen für Nord, Süd, Schweiz und Schweden.

  Siehe auch Philips B3X81U /69

• Net weight (2.2 lb = 1 kg)
• 2.5 kg / 5 lb 8.1 oz (5.507 lb)

• Price in first year of sale
• 198.00 HFL

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
