• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 268955

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 EF85 EABC80 ECH81 EM80 EL84 EZ80

• Main principle
• ZF/IF 460/10700 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 145; 165; 220; 245 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: B4X23A /89 - Philips; Eindhoven tubes

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 550 x 232 x 212 mm / 21.7 x 9.1 x 8.3 inch

• Mentioned in
• -- Original-techn. papers. (Service manual 93 746 11.1.90)

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
