B5SA85A
Philips Chilena S.A.
- Country
- Chile
- Manufacturer / Brand
- Philips Chilena S.A.
- Year
- 1959 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 122117
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110/220 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 6 inch = 15.2 cm
- Power out
- 5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: B5SA85A - Philips Chilena S.A.
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 630 x 270 x 290 mm / 24.8 x 10.6 x 11.4 inch
- Notes
- Dial localizado con nombre de principales emisoras chilenas. Conexiones para parlante adicional y tocadiscos.
- Net weight (2.2 lb = 1 kg)
- 11.5 kg / 25 lb 5.3 oz (25.33 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Leonardo Ruz. See "Data change" for further contributors.
