- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1960/1961
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 249319
from technical service manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 145; 165; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
- Power out
- 7 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: B5X04A /00 - Philips; Eindhoven tubes
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 552 x 242 x 216 mm / 21.7 x 9.5 x 8.5 inch
- Notes
-
AM radio with built-in ferroceptor:
- LW: 150 - 260 kHz.
- BC: 517 - 1620 kHz.
- SW: 5,95 - 18,2 MHz.
FM radio with dipole antenna input: 87,5 - 100 MHz.Amplifier: 2 x 3,5 W in 800 Ohm (loudspeakers AD3700AM).Dial lamps: 8024N (6.3V / 300mA, bajonet).
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Radiomuseum Olen Museum. See "Data change" for further contributors.
