BD433A /16
Philips - Schweiz
- Country
- Switzerland
- Manufacturer / Brand
- Philips - Schweiz
- Year
- 1953/1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295388
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: BD433A /16 - Philips - Schweiz
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 534 x 332 x 234 mm / 21 x 13.1 x 9.2 inch
- Notes
-
Wie Philips Jupiter 54 BD433A, aber mit nur einem Lautsprecher und 6 Positionen des Spannungswählers.
Produktion Philips Deutschland (Wetzlar) für den Export in die Schweiz.
- Net weight (2.2 lb = 1 kg)
- 9.8 kg / 21 lb 9.4 oz (21.586 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
