Bellini D23T710 /02 /06 Ch= D6
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1967–1969
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 103877
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Number of Transistors
- 11
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Bellini D23T710 /02 /06 Ch= D6 - Philips Radios - Deutschland
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 670 x 510 x 420 mm / 26.4 x 20.1 x 16.5 inch
- Notes
-
VHF-Band I und III, UHF-Band IV und V. Gerät ist mit Chassis D6 ausgerüstet.
Ausführungen: -02 dunkel, -06 hell
- VHF/UHF Kanalwähler Typ Pi-1 3112 218 50020 (HA 363 50) 4812 210 57001 mit Drucktastenbedienung
- Fernbedienung Typ 67 NT1174
- Net weight (2.2 lb = 1 kg)
- 26 kg / 57 lb 4.3 oz (57.269 lb)
- Source of data
- Handbuch VDRG 1968/1969
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Franz Born †. See "Data change" for further contributors.
