BIF430A-01
Philips Electrical (Ireland) Ltd.; Dublin
- Country
- Ireland
- Manufacturer / Brand
- Philips Electrical (Ireland) Ltd.; Dublin
- Year
- 1954 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 304081
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 22 cm = 8.7 inch
- Material
- Bakelite case
- from Radiomuseum.org
- Model: BIF430A-01 - Philips Electrical Ireland Ltd
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 480 x 325 x 200 mm / 18.9 x 12.8 x 7.9 inch
- Notes
-
Internal ferrite aerial manually turning.
Phono input, tone control.The intercom unit Interphone AF7800 can be retrofitted.
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
