- Country
- Ireland
- Manufacturer / Brand
- Philips Electrical (Ireland) Ltd.; Dublin
- Year
- 1957 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 222440
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: BIF 260U - Philips Electrical Ireland Ltd
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 12.4 x 8 x 6.5 inch / 315 x 203 x 165 mm
- Net weight (2.2 lb = 1 kg)
- 7.75 lb (7 lb 12 oz) / 3.519 kg
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Jose Casas-Avalos. See "Data change" for further contributors.
