• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1949

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 96961

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• UCH21 UAF41 or UAF42 UAF41 or UAF42 UBL21 UY1N

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• AC/DC-set / 110; 125; 200; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: BX480U - Philips; Eindhoven tubes

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 470 x 300 x 230 mm / 18.5 x 11.8 x 9.1 inch

• Notes
• AM radio for external antenna:
  • LW: 150 - 420 kHz.
  • BC: 517 - 1620 kHz.
  • SW1: 5,94 - 9,37 MHz.
  • SW2: 9,37 - 13,96 MHz.
  • SW3: 11,54 - 17,65 MHz.
  • SW4: 15 - 22,2 MHz.
  Loudspeaker: 9696-05 (5Ω).
  Dial lamp: 2x 8095D (E10, 19V/90mA).

• Price in first year of sale
• 260.00 Hfl

• Source of data
• Technisch- Commercieel - Radio Vademecum Staleman

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (4)
• -- Schematic

• Author
• Model page created by John Koster. See "Data change" for further contributors.
