• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1956

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 205801

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• DK96 DF96 DF96 DAF96 DM71 DAF96 DL96 DL96

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Storage and/or dry batteries / 1.5 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch

• Power out
• 0.2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: BX659B - Philips; Eindhoven tubes

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 630 x 410 x 230 mm / 24.8 x 16.1 x 9.1 inch

• Notes
• Energy saving switch (Normal / Economic). Dial lamp 2x 7100D

  Bands covered:
  LW: 150 - 405 kHz
  AM: 517 - 1622 kHz
  SW: 1.6 - 5.1 MHz
  SW: 4.95 - 14 MHz
  SW: 14 - 22 MHz.

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Mentioned in
• -- Schematic
