- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 144899
Teamwork Pandu Rajan and Bernhard Nagel
From Pieter de Kock site -with permission
From Pieter de Kock site -with permission
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 452 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: BX665X - Philips; Eindhoven tubes
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 580 x 355 x 260 mm / 22.8 x 14 x 10.2 inch
- Notes
- Chassis is in two parts. Some models had tube 1UA for the AVC diode and some had selenium rectifier. This model was imported into India in 1947. Price 600 Rupias. It has 4 SW bands and 1 MW band. It has band spread on 16 m, 20 m, 25 m, 30 m, 40 m & 50 m. Band spread is achieved by a special 6 section tuning condenser having special vanes. See also similar model BX660X with LW, MW and SW.
- Net weight (2.2 lb = 1 kg)
- 13.5 kg / 29 lb 11.8 oz (29.736 lb)
- Price in first year of sale
- 600.00 INR
- Source of data
- - - Data from my own collection
- Author
- Model page created by Pandu Rajan. See "Data change" for further contributors.
