• Country
• Spain

• Manufacturer / Brand
• Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona

• Year
• 1965 ?

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 320562

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• ZF/IF 38900 kHz; 2 AF stage(s)

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Caja Acústica AD-5059 - Philips Ibérica, COPRESA,

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes

• Philips Ibérica, S.A.E., Caja Acústica (Bafle) AD-5059



• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
