Cassette Tape Recorder SR3200 /14
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1980 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 239655
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 18
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Cassette Tape Recorder SR3200 /14 - Philips; Eindhoven tubes
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 418 x 120 x 195 mm / 16.5 x 4.7 x 7.7 inch
- Notes
-
Dolby-B Noise Reduction.
3 - Digit Mechanical Counter.
Analog Needle Meters.
One semiconductor per type listed.
- Net weight (2.2 lb = 1 kg)
- 3.7 kg / 8 lb 2.4 oz (8.15 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
