Compact Disc Midi System FCD185 /30 /35
Philips, Singapore
- Country
- Singapore
- Manufacturer / Brand
- Philips, Singapore
- Year
- 1989 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 259783
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Other Combination - see Notes
- Power type and voltage
- Alternating Current supply (AC) / 120; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 20 W (undistorted)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Compact Disc Midi System FCD185 /30 /35 - Philips, Singapore
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 466 x 758 x 466 mm / 18.3 x 29.8 x 18.3 inch
- Notes
-
Philips Stereo Compact Disc Midi System FCD185
- Record player type HP7D277
- Integrated stereo amplifier with 5 band graphic equalizer
- Double cassette deck
- CD Player
According to the schematic, one model has voltage change by welding (service solution) and another by voltage selector
Doppelcassettendeck, Plattenspieler & CD Player. 5 Band Equalizer.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by a member from A. See "Data change" for further contributors.
